Available Variants
Full Specifications
Network
| Technology | GSM / CDMA / HSPA / LTE / 5G |
| 2G bands | GSM 850 / 900 / 1800 / 1900, CDMA 800 |
| 3G bands | HSDPA 800 / 850 / 900 / 1700(AWS) / 2100 |
| Speed | HSPA, LTE, 5G |
| 4G bands | 1, 3, 4, 5, 8, 18, 19, 26, 28, 34, 38, 39, 40, 41, 42, 48, 66 |
| 5G bands | 1, 3, 5, 8, 28, 38, 40, 41, 48, 66, 77, 78 SA/NSA |
Launch
| Announced | 2024, December 26 |
| Status | Available. Released 2024, December 26 |
Body
| Protection | IP65 dust tight and water resistant (low pressure water jets) |
| SIM | Nano-SIM + Nano-SIM |
| Build | Glass front (Crystal Shield Glass), glass back (Crystal Shield Glass), aluminum frame |
| Weight | 206 g or 223 g (7.27 oz) |
| Dimensions | 161.7 x 75.8 x 8.1 mm (6.37 x 2.98 x 0.32 in) |
Display
| Size | 6.78 inches, 111.7 cm2 (~91.2% screen-to-body ratio) |
| Resolution | 1264 x 2780 pixels (~450 ppi density) |
| Protection | Crystal Shield Glass |
| Type | LTPO AMOLED, 1B colors, 120Hz, HDR10+, Dolby Vision, 800 nits (typ), 1600 nits (HBM), 4500 nits (peak) |
Hardware & Software
| OS | Android 15, ColorOS 15 |
| Chipset | Qualcomm SM8650-AB Snapdragon 8 Gen 3 (4 nm) |
| CPU | Octa-core (1x3.3 GHz Cortex-X4 & 3x3.2 GHz Cortex-A720 & 2x3.0 GHz Cortex-A720 & 2x2.3 GHz Cortex-A520) |
| GPU | Adreno 750 |
Memory & Storage
| Card slot | No |
| Storage Type | UFS 4.0 |
| Internal | 256GB 12GB RAM, 256GB 16GB RAM, 512GB 12GB RAM, 512GB 16GB RAM, 1TB 16GB RAM |
Main Camera
| Triple | 50 MP, f/1.8, 24mm (wide), 1/1.56", 1.0µm, PDAF, OIS 8 MP, f/2.2, 16mm, 112˚ (ultrawide), 1/4.0", 1.12µm 2 MP (macro) |
| Video | 4K@30/60fps, 1080p@30/60/120/240fps, gyro-EIS, OIS |
| Features | Color spectrum sensor, Dual-LED flash, HDR, panorama |
Selfie Camera
| Single | 16 MP, f/2.4, 24mm (wide), 1/3", 1.0µm |
| Video | 1080p@30fps, gyro-EIS |
| Features | HDR, panorama |
Sound
| Loudspeaker | Yes, with stereo speakers |
| 3.5mm jack | No |
Connectivity
| WLAN | Wi-Fi 802.11 a/b/g/n/ac/6/7, dual-band |
| Infrared port | Yes |
| USB | USB Type-C 2.0 |
| Radio | No |
| NFC | Yes |
| Positioning | GPS (L1+L5), GLONASS (G1), BDS (B1I+B1c+B2a), GALILEO (E1+E5a), QZSS (L1+L5) |
| Bluetooth | 5.4, A2DP, LE, aptX HD, LHDC 5 |
Features
| Sensors | Fingerprint (under display, optical), accelerometer, gyro, proximity, compass |
Battery
| Charging | 80W wired, 18W PD, 55% in 15 min, 100% in 35 min |
| Type | Si/C Li-Ion 6415 mAh |
Community Discussions
(0)No Discussions Yet
Be the first to ask a question, share a review, or give advice about the OnePlus Ace 5.
Start a DiscussionFrequently Asked Questions
Description
Overview & Display
The OnePlus Ace 5 brings a premium feel with its Crystal Shield Glass front and back, paired with an aluminum frame that keeps things sturdy yet elegant. Weighing between 206 and 223 grams depending on configuration, the phone measures 8.1mm thick, making it comfortable to hold for extended periods. The IP65 rating means it handles dust and low-pressure water jets without issue. The 6.78-inch LTPO AMOLED display is where things get exciting — with a billion colors, HDR10+, and Dolby Vision support, content looks vibrant and immersive. The 120Hz refresh rate adapts smoothly, and peak brightness hitting 4500 nits means outdoor visibility stays excellent. With a 91.2% screen-to-body ratio, the bezels are minimal, making videos and games feel expansive. Stereo speakers round out a solid multimedia experience.
Under the hood, the Snapdragon 8 Gen 3 built on a 4nm process delivers flagship-level performance. The octa-core CPU with a Cortex-X4 prime core running at 3.3GHz handles demanding apps effortlessly. Paired with the Adreno 750 GPU, gaming stays smooth even at high settings. RAM options go up to 16GB, and storage reaches 1TB using UFS 4.0, ensuring fast app loads and plenty of space. Running Android 15 with ColorOS 15, the software feels modern and responsive. Whether you're switching between apps or running heavy games, daily multitasking stays snappy.
Camera & Battery
The OnePlus Ace 5 features a triple rear camera setup led by a 50MP main sensor with optical image stabilization and a wide f/1.8 aperture. The 1/1.56" sensor captures solid light intake, and OIS helps keep shots steady. An 8MP ultrawide with a 112-degree field of view adds versatility for landscapes and group shots, while the 2MP macro handles close-up detail work. Video recording is capable — 4K at 60fps with gyro-EIS and OIS means footage stays smooth. You can also shoot 1080p at up to 240fps for slow-motion clips. HDR and panorama modes are available, along with a color spectrum sensor for accurate tones. The 16MP front camera shoots 1080p video with gyro-EIS and supports HDR for selfies.
Battery life is a standout with a massive 6415mAh silicon-carbon cell that easily handles a full day of heavy use. When it's time to recharge, 80W wired charging gets you to 55% in just 15 minutes and fully charged in 35 minutes. There's also 18W PD support for compatibility with standard chargers. Connectivity is comprehensive — Wi-Fi 7, Bluetooth 5.4 with aptX HD, NFC, and an infrared port for controlling home appliances. Dual SIM support and extensive 5G band coverage make it travel-friendly. The under-display optical fingerprint sensor works reliably, and the positioning system covers GPS, GLONASS, BDS, Galileo, and QZSS for accurate navigation.
Who Should Buy This
The OnePlus Ace 5 is ideal for users who want flagship performance without compromise. If you're a power user who games heavily, streams content, and multitasks throughout the day, the Snapdragon 8 Gen 3 combined with up to 16GB RAM and 1TB storage will keep up effortlessly. The massive battery suits those who hate carrying chargers around. Photography enthusiasts who want a versatile camera setup with 4K video will appreciate the rear triple system. However, if you need a 3.5mm headphone jack, expandable storage, or FM radio, you'll need to look elsewhere. This phone targets users who prioritize speed, display quality, and endurance above all else.
Pros
- Snapdragon 8 Gen 3 delivers flagship-level performance
- 6415mAh battery easily lasts a full day
- 80W fast charging reaches full in 35 minutes
- LTPO AMOLED display with 4500 nits peak brightness
- Up to 1TB storage with UFS 4.0 speed
Cons
- No 3.5mm headphone jack included
- No expandable storage via microSD card
- No FM radio support available
- Ultrawide camera limited to 8MP resolution
Verdict
The OnePlus Ace 5 delivers a compelling package with its Snapdragon 8 Gen 3 chipset, stunning LTPO AMOLED display, and massive 6415mAh battery. The 80W charging keeps downtime minimal, and the camera system covers most scenarios with capable 4K video recording. The lack of a headphone jack, expandable storage, and FM radio are notable limitations worth considering. For users seeking raw performance, excellent battery life, and a vibrant display, this phone is a strong choice that won't disappoint.
